1064 Nm 532nm Q-Switched ND YAG Laser Machine For Tattoo Removal And Freckle Removal

1064 Nm 532nm Q-Switched ND YAG Laser Machine For Tattoo Removal And Freckle Removal

1064 Nm 532nm Q-Switched ND YAG Laser Machine For Tattoo Removal And Freckle Removal

Product Details:

Place of Origin: China
Brand Name: KES
Certification: Medical CE, CE Certificate, ISO13485, SGS
Model Number: MED-860

Payment & Shipping Terms:

Minimum Order Quantity: 1 units
Price: USD 1000 - 6666 / set
Packaging Details: Aluminium Packing Box
Delivery Time: 7 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 800 units per month
Contact Now
Detailed Product Description
Product Name: Portable 1064nm & 532nm Q Switch ND Yag Laser Tattoo Removal Machine Cooling: Self-contained, Closed Water Cycle
Electrical Requirements: 100-240VAC, 20A Max., 50/60Hz Spot Size: Adjustable Spot Size 2-10 Mm(Diameter)
Energy: 1064nm 100-1000mJ 532nm 100-500mJ Laser Type: Q-switched KTP Nd:YAG
Pulse Rate: Adjustable From 1-10Hz

Popular 1064 nm 532nm nd yag laser machine for tattoo removal and freckle removal



What is Q‐switched Nd: YAG Laser?



High focus 1064nm/532nm laser energy transmits/transfer instantaneously to target lesion pigmentation site within extremely short period(6ns) and then results in an instantaneous pigmentation blasting.The pigmentation tiny/small particles are shattered into fragments ,some fragments in the epidermis will be removed directly and deep tiny fragment in the dermis will be devoured/absorbed by phagocytes and then eliminated by lymphatic system,so achieve the best result for pigmentation remova




Q-Metrx 1000 laser is the newest generation of Electro-Optic Q-switched Nd:YAG Solid State Laser. It is ideal for treatment of wide range of skin pigment, especially for black, blue, brown and red tattoos. It has been proved highly successful for tattoo removal including eye brow, eye line, body tattoo, pigmented lesion, lip line and allergic resource of red dyestuff. Q-Metrx 1000 is professional designed to get rid of Nevus of Ota, Coffee spot, Birthmark, Skin Whitening, Pigmented Lesions, Age Spot, etc.



1064 Nm 532nm Q-Switched ND YAG Laser Machine For Tattoo Removal And Freckle Removal



Quasi-Long mode:



Quasi-Long Pluse (pulse width 300us @ 1064nm) is a combination of toning and lifting which enables pigmented cells to absorb the laser selectively. It stimulates collagen by the destruction of pigmented cells, and it is useful to general skin for regenerating afater peeling, imporving loose skin, and minimizing large pores.



DUAL-Q mode:

DUAL-Q mode delivers 2 pulses of constant energy of laser power in a very short period of time. Compared to previous laser toning procedures, its energy is much higher. In order to reduce side effects of high energy laser such as hypopigmentation. Pigmentation or melasma recurrence, the high energy is divided into two, to increase the effect while reducing side effects. Q-DUAL-Q mode can be done at both 1064nm and 532nm wavelengths.



Advantages



1. Innovative laser technology, strict in technical detection, precise in manufacture, stable and effective in performance.
2. Special designed cooling system ensures constantly working, more than 10 hours without stopping per time.
3. No injury to normal tissue;
4. Remove pigmentation without side effects or scar;
5. Short treatment period with outstanding effect.



Before&After:



1064 Nm 532nm Q-Switched ND YAG Laser Machine For Tattoo Removal And Freckle Removal



Technical Specifications:



Light source: Electro-Optic Q-switched Nd:YAG Solid State Laser
Display Screen: 10.4 inch Color Touch Display Screen
Wavelength: 1064nm or 532nm
Spot Size: Adjustable Spot Size 2-10 mm(Diameter)
Energy: 1064nm 100-1000mJ 532nm 100-500mJ
Pulse duration: 5-7ns
Pulse rate: Adjustable from 1-10Hz
Aiming Beam: Red Diode Laser(On, Off, Blinking Available)
Power supply: 220v±10%,50/60hz
Cooling system Air cooling and water cooling
Continuous working time Can work continuously for 24 hours (when the room temperature is 25 degrees)
Humidity <=85%



Machine show:



1064 Nm 532nm Q-Switched ND YAG Laser Machine For Tattoo Removal And Freckle Removal



OEM/ODM are welcomed!!!
Any questions, please don't hesitate to contact us!!!

Welcome to inquiry to info@keslaser.com!
