500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength

500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength
500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength

Large Image :  500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength

Product Details:
Place of Origin: China
Brand Name: KES
Certification: CE FDA
Model Number: MED-810A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1 - 9999 / set
Packaging Details: Aluminum trunk
Delivery Time: 18 workdays
Payment Terms: T/T,
Supply Ability: 500 sets per month
Detailed Product Description
Product Name: Q - Switch Nd Yag Laser Machine Rated Power 500w Laser Wavelength 1064 / 532 Nm Key Word: Tattoo Removal
Spot Size: 2-8mm Pulse Width: Max 10ns
Dimension: 45*40*57cm Net Weight: 25 Kgs
High Light:

q switched laser tattoo removal

,

diode laser treatment for hair removal

500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength




Working Principle:

 Q-switched Nd: yag laser device applies the explosion effect of laser, which can permeate the cuticle efficiently to the pigment mass in the derma. The laser pulses in nanosecond range has very high energy. When the laser is absorbed by according pigment, the pigment mass expands quickly and breaks into particles which are eliminated through phagocytes. Then the shattered pigment is absorbed by the body and excreted out. Gradually the pigment becomes lighter and lighter till disappearing.
Utilizing the explosive effect of the Nd: YAG laser, the laser permeate the epidermis into the dermis which includes amount of pigment mass. Since the laser pulses in nanosecond but with super high energy, the shot pigment mass swell quickly and breaks into small pieces, which will be eliminated through metabolic system.
 Q-Switch laser is a new pigment laser system with a new look, it is the perfect combination of pixel laser and Q-Switch technology, can be safely and effectively used to a variety of pigmented lesions, Melasma treatment and warm and cool colors tattoo removal.

Q-switching, sometimes known as giant pulse formation, is a technique by which a laser can be made to produce a pulsed output beam. The technique allows the production of light pulses with extremely high (gigawatt) peak power, much higher than would be produced by the same laser if it were operating in a continuous wave(constant output) mode. Compared to modelocking, another technique for pulse generation with lasers, Q-switching leads to much lower pulse repetition rates, much higher pulse energies, and much longer pulse durations. The two techniques are sometimes applied together.


Applications:
1)  Removal tattoo, eyeliner, eye brow, remove black, red, blue, and all kinds of color pigment,
2)  Remove dermis spot, fleck, black nevus, age pigment, birthmark and Nevus of Ota
3)  The 1064nm wavelength mainly for black, blue, cyan pigment
4)  The 532nm wavelength mainly for red, coffee, brown pigment.

*  Features&Advantages:
1) Truly portable, continent
2) New-developed hand piece
3) Infrared ray aiming.
4) Water-flow monitor
5) Water flow and temp monitor

6) Plug and play function
7) CE&CE Medical approved, the production processes are according to ISO13485,93/42/EEC standards .

Technical parameter:



Wavelength

1064nm&532nm

Spot Diameter

2~5mm

Width of Pulse

<10ns

Pulse Energy

532/1064nm (0~800mJ)

Repetition Rate

1-6Hz adjustable

Operation Interface

6 dual color LCD

Power

500W

YAG Bar Size

7

Aiming Beam

Guided by red light

Cooling Systems

Air Cooling & Close Water Circulation

Electrical Requirements

100/110V,50~60HZ OR 230~260V, 50~60HZ

Dimension

50cm*38cm*40cm(L*W*H)

Net Weight

12kgs


picture of treatment:

500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength 0

500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength 1

500w Q - Switch Nd Yag Laser Machine 1064 / 532 Nm Laser Wavelength 2
