| Key Word: | Q Switch Nd Yag Laser Tattoo Removal System | Color: | White+grey |
|---|---|---|---|
| Aiming Beam: | 5mw Red Diode Laser, 635 Nm | Laser Type: | Q-switched KTP Nd:YAG |
| Spot Size: | 2-8mm | Certificate: | Medical CE, CE Certificate, ISO13485, SGS, FDA Pending |
| Application: | For Commercial | Application: | For Commercial |
| Application: | For Commercial | After-sales Service Provided: | Online Support, Video Technical Support |
| After-sales Service Provided: | Online Support, Video Technical Support | Warranty: | 2 Years |
| Brand: | KES | Quantity: | 1 |
| Quantity: | 1 | Quantity: | 1 |
| Lead Time: | 15 | ||
| High Light: | q switched laser tattoo removal,diode laser treatment for hair removal |
||
Black Portable Q-switched Laser Equipment for Birth Mark Removal / Eyeline - cleaning
Model No.: AL1
Accessories
1. Handles 2. Head with 532nm/1064nm wavelength 3. Packing box 4. Laser Protective Glasses 5.Foot switch 6. Keys,Funnel and Power cord.
Technical Specifications:
| Wavelength | 1064nm & 532nm |
| Energy | 1-1000mJ |
| Laser Type | Q-switched KTP Nd:YAG |
| Spot Size | 2-5mm |
| Repetition Rate | 1-6Hz |
| Pulse Width | <10ns |
| YAG Bar Size | 6 |
| Power | 250W |
| Aiming Beam | 5mw red diode laser, 635 nm |
| Stand-by Working | Continuously for 12 hours |
| Cooling | Self-contained, closed water cycle |
| Display | 6" Dual Color LCD Screen |
| Electrical Requirements | 100-240VAC, 20A max., 50/60Hz |
| Net Weight | 14 kgs |
| Dimensions (WxDxH) | 42*23*34cm |
Principle :
The laser from skincare laser machine penetrates surface skin, reaches pigment in derma. Shortly after absorbing great laser energy, the pigment expands and breaks into small particles which are to be removed from the body. The treatment purpose is achieved.
Main Curing Principle of Vascular Lesions is as follows:
Firstly, the fixed wavelength laser acts on the target tissues.
Secondly, by the thermal effect of the laser, the laser lights on the abnormal vascular.
Thirdly, after the hemoglobin in the vascular absorbs the very high energy in very short time, it will concrete, and finally disappear.
Application:
1. Q switch 1064 nm laser: the suitable for treatment is tattoos, eyebrow drawing, lip mark lines and eye mark lines.
2. Q switch 532nm laser the suitable for treatment is spot of shallow layer coffee, red and brown tattoos, eyebrow drawing, lip mark lines and eye mark lines.
1. Warranty
12 month for nd yag laser machine, Lifelong Maintenance Service
2. Once the machine have any malfunction during the operation, how to do?
Please rest assure if you met such problem, because KES has a professional after-sale service team which can reach you immediately and solve the machine’s problem within 1-3 days.
For details, please contact with us freely
3. If the machines broken during the shipment, how to do?
Generally there will be transportation insurance in the shipment, once there is any damage during the transportation, KES will help you to solve the claims with the insurance companies to collect your money back in time.
